Clutch Fluid; DOT4 only or DOT3 ok?

Old 07-12-2017, 01:18 PM
  #1
Member
Squid
Thread Starter

Join Date: May 2011
Location: Fair Lawn, NJ
Posts: 65
redhawk98 is on a distinguished road
Clutch Fluid; DOT4 only or DOT3 ok?

I just finished replacing the oil and filter on the hawk. Went to warm it up so oil will fill the oil filter and let it warm up. Bike is on stands so I wanted to run it through the gears to get the new oil circulating everywhere.

However, when I pulled the clutch lever in I found it very difficult to shift into first. I pushed down pretty hard and heard a bit of grinding but got first to engage. Was able to go into second fairly easy when I noticed the wheel would not stop spinning when the clutch lever was pulled in, just kept on spinning like it's completely engaged.

I figure the fluid is old and needs replacing. Manual states DOT4 brake fluid and nothing else as others are not compatible. Can anyone chime in on this? Should DOT3 be avoided??? I bought the bike used, atleast two previous owners, not clue as to what's in there right now. TIA.
redhawk98 is offline
Old 07-12-2017, 04:10 PM
  #2
Moderator
MotoGP

E.Marquez's Avatar

Join Date: Apr 2006
Location: Kempner, TX
Posts: 4,173
E.Marquez is on a distinguished road
Correct DOT 3/4 should not be used emplace of the other. Technically they can be mixed with no ill effects, but they do not have the same capabilities .

DOT 5.1 can be used in replacement of either 3 or 4
E.Marquez is offline
Old 07-12-2017, 05:03 PM
  #3
Moderator
MotoGP

Wolverine's Avatar

Join Date: Jul 2007
Location: Gettysburg, Pa
Posts: 4,446
Wolverine is on a distinguished road
Just buy yourself a new sealed container of the 4 and do it as Honda requests.
Wolverine is offline
Old 07-13-2017, 06:19 AM
  #4
Member
Squid
Thread Starter

Join Date: May 2011
Location: Fair Lawn, NJ
Posts: 65
redhawk98 is on a distinguished road
Thanks for the info E.Marquez.

What do you suggest I do Wolverine? I don't know what's in there right now. Is it safe to drain all the system and then refill with DOT4 or should I clean the lines/master cylinder/slave cylinder with alcohol first? TIA
redhawk98 is offline
Old 07-13-2017, 03:38 PM
  #5
Moderator
MotoGP

Wolverine's Avatar

Join Date: Jul 2007
Location: Gettysburg, Pa
Posts: 4,446
Wolverine is on a distinguished road
Draw all the the contents of the res out with a suction devise. I use one of these, pick one and go.


Then refill with fresh and bleed about 2 res worth through the system. Should do the trick, easy peazy
Wolverine is offline
Old 07-15-2017, 06:31 AM
  #6
Senior Member
SuperBike

xeris's Avatar

Join Date: Sep 2010
Location: Bisbee, AZ
Posts: 1,453
xeris is on a distinguished road
xeris is offline
Old 07-16-2017, 07:52 PM
  #7
Member
Squid
Thread Starter

Join Date: May 2011
Location: Fair Lawn, NJ
Posts: 65
redhawk98 is on a distinguished road
Thanks for the clarification Wolverine, picked up Prestone DOT4 tonight and will bleed the clutch tomorrow.

Good link for educational info xeris, but I didn't find anything there on what happens if DOT3 and 4 get mixed, or how to clean lines if that's even necessary.

As of now, I will bleed two maybe three reservoir worth and probably do the brakes as well.
redhawk98 is offline
Old 07-17-2017, 07:38 AM
  #8
Member
Squid
Thread Starter

Join Date: May 2011
Location: Fair Lawn, NJ
Posts: 65
redhawk98 is on a distinguished road
Ok, here's the deal. I replaced all the clutch fluid at least 4 res full. No bubbles, clutch handle is firm. However, when the bike is on a rear stand with the rear wheel in the air, it is still spinning in each gear with the clutch lever pulled in all the way to the bar (I even extended the leverage to full range even though my hands are on the smaller side). I don't remember this phenomenon happening before. I took it for a quick spin around the block and it feels and shifts fine, idles fine as well. Any ideas? or is this normal?

PS
The oil I used now was conventional 10w40 motorcycle specific oil, not car oil. The oil that was in it before was also motorcycle specific oil 10w40 but synthetic. Could that affect it?
redhawk98 is offline
Old 07-17-2017, 09:56 AM
  #9
Moderator
MotoGP

Wolverine's Avatar

Join Date: Jul 2007
Location: Gettysburg, Pa
Posts: 4,446
Wolverine is on a distinguished road
You're good to go. That's normal (tire spinning).
Wolverine is offline
Old 07-18-2017, 04:05 AM
  #10
Senior Member
SuperBike

Wicky's Avatar

Join Date: Sep 2008
Location: Essex, UK
Posts: 1,624
Wicky is on a distinguished road
Wheel spinning - perfectectly normal

The oil that was in it before was also motorcycle specific oil 10w40 but synthetic. Could that affect it?
Have you changed it to semi synthetic? As some owners report clutch slip using fully synthetic...
Wicky is offline
Old 07-18-2017, 04:38 AM
  #11
Moderator
MotoGP

Wolverine's Avatar

Join Date: Jul 2007
Location: Gettysburg, Pa
Posts: 4,446
Wolverine is on a distinguished road
Originally Posted by Wicky View Post
Have you changed it to semi synthetic? As some owners report clutch slip using fully synthetic...
Full synthetic DOES NOT cause clutch slip... This should only be reported as personal experience. I've used full syn in my VTR for 10 years... NO slip.
I work at a motorcycle shop as the only mechanic. I pour full syn regularly, never had complaint of slip...
Wolverine is offline
Old 07-18-2017, 09:45 AM
  #12
Senior Member
Superstock

Fastguy59's Avatar

Join Date: Nov 2014
Location: Middletown, CT
Posts: 408
Fastguy59 is on a distinguished road
As a rule all brake/clutch fluid should be changed every 24 months. Brake is very, very hygroscopic and the fluid starts absorbing moisture from the air as soon as you open the can. So what does this do?
1. Brake fluid gets hot, when it does the O2 part of H2O gets released, now you have spongy brakes, they need to be bleed.
2. The H2O is a an corrosive/oxidizer bad for your master and slave cylinders
3. H2O drops the boiling point of your brake fluid. The higher the boiling point of a fluid the more firm your lever will feel and the easier it is to modulate your braking.
4. Caveat, super high boiling point DOT4 fluids used in racing give amazing feel and lever firmness, but they absorb moisture at a higher rate than standard DOT 4 fluids and so need changing more regularly...
Fastguy59 is offline
Old 07-18-2017, 09:48 AM
  #13
Senior Member
Superstock

Fastguy59's Avatar

Join Date: Nov 2014
Location: Middletown, CT
Posts: 408
Fastguy59 is on a distinguished road
No clutch slip for me either I have been using full synthetic in my road and race bike since 1983. As a matter a fact after a break in of 200 miles all my race bike were slick 50 treated in with the synthetic oil, still never a problem. I always have used OEM clutch pack...
Fastguy59 is offline
Old 07-18-2017, 05:17 PM
  #14
Moderator
MotoGP

E.Marquez's Avatar

Join Date: Apr 2006
Location: Kempner, TX
Posts: 4,173
E.Marquez is on a distinguished road
Originally Posted by redhawk98 View Post

Good link for educational info xeris, but I didn't find anything there on what happens if DOT3 and 4 get mixed, or how to clean lines if that's even necessary..
Nothing happens, its not incompatibility at issue, its different capabilities.

Just look at the two fluid general specs.
DOT 3:
The very common DOT3 specification brake fluid will be made from a glycol base and will contain glycol ethers and additives to inhibit corrosion (to prolong braking component life) and promote lubricity (to extend seal life). DOT 3 fluids have a minimum dry boiling point of 401F (205C) minimum and a minimum wet boiling point of 284F (140C). It will be clear to amber in color and be hygroscopic (absorbs moisture). It will absorb 1% to 2% of moisture content per year, depending on climate and operating conditions. This moisture absorption will reduce its boiling point, eventually lowering down to the wet boiling point or even below. It does not require a system flush before using and can be mixed with DOT 4 and DOT 5.1 without damage to the system. As with all glycol-based fluids, it can damage the paint on a vehicle.
DOT 4:
Also containing glycol, the SAE J1704 specification considers DOT 4 to be a borate ester base fluid and is also clear to amber in color. While somewhat less hygroscopic than DOT 3, it still absorbs moisture, with a minimum dry boiling point of 446F (230C) and minimum wet boiling point of 311F
(155C). DOT 4 is used in many European vehicles, as well as for high altitude, towing, or highspeed braking situations. It is often favored for the newer ABS systems. DOT 4 usually contains anticorrosion and lubricity increasing additives and can be mixed with DOT 3 with no system damage. It
will also damage the paint on a vehicle if not flushed with water immediately. Many of the high performance or racing DOT 4 fluids will contain other additives to increase fluid performance well beyond the minimum specifications.
DOT 3 used in a system designed around the qualities and specs of DOT 4 will see fluid, and thus system failure.
DOT 4 "added" to a system with DOT 3 will not see any increase in fluid performance as the two are now mixed. Flush the DOT completely from the system and fill with DOT4 or 5.1 and you will see a fluid performance increase.

DOT 5 is silicone based and is not compatible with any other type ..they do not mix at all, or in any case separate. DOT5 is more compressible that DOT3, 4, 5.1 And is more effected by heat. It is not hygroscopic (it does not absorb moisture) thats good and bad,,the fluid retains its boiling point as it is not "wet" the bad, its allows the moisture that DOES get in the system to pool and cause corrosion.
E.Marquez is offline
Old 07-18-2017, 06:12 PM
  #15
Member
Squid
Thread Starter

Join Date: May 2011
Location: Fair Lawn, NJ
Posts: 65
redhawk98 is on a distinguished road
Thanks for all the responses. E.Marquez, I did read the whole article you provided and understood it, but as I'm not a chemical or component engineer did not assume anything about the differences in properties and how they react to each other (Except or the silicone base stuff, that was pretty clear).

Since there was so much fluid left and the longer this stuff sits in an open container the less usable it becomes, I flushed both front and rear brakes to boot. Now all I have to do is flush the cooling system and she'll be like new again

Any consensus about using the Honda car 50/50 Type 2 Coolant? Have left over from my radiator change and thought it'll go to good use in the hawk. TIA.
redhawk98 is offline
Old 07-19-2017, 03:24 PM
  #16
Moderator
MotoGP

E.Marquez's Avatar

Join Date: Apr 2006
Location: Kempner, TX
Posts: 4,173
E.Marquez is on a distinguished road
Originally Posted by redhawk98 View Post
Any consensus about using the Honda car 50/50 Type 2 Coolant? .
If it is designed for a modern car and aluminum radiator it will be fine
E.Marquez is offline
