could this be done with bafflectomy pipes
10-06-2008, 05:46 PM
#1
Member
Squid
Thread Starter
Join Date: Sep 2008
Location: EastTN
Posts: 50
could this be done with bafflectomy pipes
i have completed the bafflectomy and feel like i have lost quite a bit of mid range. found this and was wondering if it would be possible to implement it to sh bafflectomized pipes.
any input would be appreciated.
http://www.nightrider.com/biketech/exhaust.htm
any input would be appreciated.
http://www.nightrider.com/biketech/exhaust.htm
10-06-2008, 06:16 PM
#2
Thats Mr Dill hole to you
Superstock
Join Date: Aug 2007
Location: Sioux Falls, SD Beeeotch
Posts: 389
i have completed the bafflectomy and feel like i have lost quite a bit of mid range. found this and was wondering if it would be possible to implement it to sh bafflectomized pipes.
any input would be appreciated.
http://www.nightrider.com/biketech/exhaust.htm
any input would be appreciated.
http://www.nightrider.com/biketech/exhaust.htm
If you where to shim your Needles on your bike you would get back your mid range a **** load of bottom end and maybe even a better tourqe curve up to top end...
By properly re-jetting the carburetor and adding a free flowing air cleaner to an engine with drag pipes, the maximum horsepower produced will improve over the stock engine. But there is a difference between usable power and maximum horsepower. The maximum horsepower of two engines may be similar, but the horsepower torque curves may be different. The area under the horsepower and torque curves defines the "power" the engine produces. The more area that is under the curve, the better the power.
And it only costs around 50 Cents to do it ....
10-06-2008, 06:44 PM
#4
Thats Mr Dill hole to you
Superstock
Join Date: Aug 2007
Location: Sioux Falls, SD Beeeotch
Posts: 389
pull the carbs or nothing... just pull the "black roundy things" off the top to remove the carb slide and take the needle out of the carb slide and drop a .030 to .060 washer on to the needle to raise your needles a bit to make the main fuel circuit come on faster of all the mods i did to my bike this was the best one hands down. thats a "quick" run down of the proc. if you serch around im sure you can find a good write up on it here on the forums
filter, your shaved cat still doesn't look happy to me.
10-07-2008, 07:21 AM
#6
Senior Member
SuperBike
Join Date: Sep 2005
Location: Buffalo, NY
Posts: 1,572
LOL No it doesn't look happy!
Back to topic, a #4 brass washer works well for shimming needles - the ones I picked up at the hardware store were .024 and are working well with my K&N (stock pipes still) so you may need to go with 2 washers or a thicker one to get you in the .040 to .060 range.
Back to topic, a #4 brass washer works well for shimming needles - the ones I picked up at the hardware store were .024 and are working well with my K&N (stock pipes still) so you may need to go with 2 washers or a thicker one to get you in the .040 to .060 range.
10-08-2008, 09:33 PM
#7
Thats Mr Dill hole to you
Superstock
Join Date: Aug 2007
Location: Sioux Falls, SD Beeeotch
Posts: 389
10-13-2008, 09:58 AM
#11
2nd mouse gets the cheese
SuperBike
Join Date: Jan 2008
Location: Beaverton, OR
Posts: 1,697
I would up the sizing on the washer seeing as drag pipes like the article is talking about tend to be a narrow diameter, making the washer in those take up nearly the entire inside diameter of the pipe. This idea basically is supposed to make you have some adjustment in you back pressure. With all the space around the bolt I don't think it is doing anything to restrick or build up pressure. Just my 2c
10-13-2008, 11:49 AM
#13
Out of my mind, back in 5
MotoGP
Join Date: Nov 2006
Location: Skurup, Sweden
Posts: 6,109
I would up the sizing on the washer seeing as drag pipes like the article is talking about tend to be a narrow diameter, making the washer in those take up nearly the entire inside diameter of the pipe. This idea basically is supposed to make you have some adjustment in you back pressure. With all the space around the bolt I don't think it is doing anything to restrick or build up pressure. Just my 2c
10-13-2008, 11:53 AM
#14
Out of my mind, back in 5
MotoGP
Join Date: Nov 2006
Location: Skurup, Sweden
Posts: 6,109
10-13-2008, 12:56 PM
#15
Member
Squid
Thread Starter
Join Date: Sep 2008
Location: EastTN
Posts: 50
prolly useless on the superhawk. i am gonna take out the baffles on my harley davidson and put these in there. they look a lot like big city thunder baffles, except only cost me about $14. i would like to adjust the washers in the carbs, but i am too scared i'd skrew it up.
10-13-2008, 01:33 PM
#16
Member
Squid
Join Date: Oct 2008
Posts: 39
I used to do Key bangers.. Can shoot a flame out about 6 inches.. Again useless but lots of fun. Scare the crap out of who ever is around. Sounds like a 12 gauge going off. LMAO
10-13-2008, 01:54 PM
#17
Out of my mind, back in 5
MotoGP
Join Date: Nov 2006
Location: Skurup, Sweden
Posts: 6,109
prolly useless on the superhawk. i am gonna take out the baffles on my harley davidson and put these in there. they look a lot like big city thunder baffles, except only cost me about $14. i would like to adjust the washers in the carbs, but i am too scared i'd skrew it up.
