Need inexpensive PAIR block off plates
06-30-2013, 02:50 PM
#3
Senior Member
Superstock
Join Date: Apr 2013
Location: SF Bay Area
Posts: 466
Procedure
Remove the seat and tank (and PLEASE mark the vacuum/vent/fuel lines to the tank so you can remember which way to reinstall them!!!)
Remove the rubber hoses going to each PAIR valve.
Remove the two bolts holding each PAIR valve in place.
Remove the PAIR valves.
You will see a small screw holding the reed stopper and reed in place. Remove the screw, flip the reed stopper to hold the reed shut, and replace the screw..
Put everything back together (3.6 ft-lb on the PAIR valve bolts)
You just disabled PAIR.
Remove the seat and tank (and PLEASE mark the vacuum/vent/fuel lines to the tank so you can remember which way to reinstall them!!!)
Remove the rubber hoses going to each PAIR valve.
Remove the two bolts holding each PAIR valve in place.
Remove the PAIR valves.
You will see a small screw holding the reed stopper and reed in place. Remove the screw, flip the reed stopper to hold the reed shut, and replace the screw..
Put everything back together (3.6 ft-lb on the PAIR valve bolts)
You just disabled PAIR.
06-30-2013, 03:19 PM
#4
Member
Squid
Join Date: May 2011
Location: SoCal
Posts: 64
07-01-2013, 06:45 PM
#7
Rex Kramer-Thrill Seeker
SuperBike
Join Date: Jan 2011
Location: Brookfield, WI
Posts: 2,312
I have superdutys pair block off plates and manual CCT's on my bike and also on my spare engine...which I actually bought from him, so it better lol
I highly recomend his products!
I highly recomend his products!
07-02-2013, 04:51 AM
#9
Senior Member
Back Marker
Join Date: Jan 2009
Location: Hills of Kentucky
Posts: 224
The "most inexpensive" ones are already on your bike.
Flip the reeds as stated above and use the covers that are there, but just get vaccuum caps for the ends.
I ran mine that way until I could afford SuperD's plates and CCTs.
Flip the reeds as stated above and use the covers that are there, but just get vaccuum caps for the ends.
I ran mine that way until I could afford SuperD's plates and CCTs.
07-14-2013, 07:53 PM
#11
Member
Squid
Squid
Join Date: Mar 2009
Location: Sherman Island, Ca.
Posts: 53
KCCO, call me confused... I do not understand how flipping the reed / stopper is beneficial??? Perhaps I am just misunderstanding your procedure? It seems to me, in it's original position the reed allows air in under the brief negative pulse in the exhaust port and conversely keeps the positive pressure from escaping through the reed, and exiting down the header as it should. I imagine the positive wave would be much more than that of the negative / vacuum wave. Either I'm missing something or what you prescribe is the reverse of what is to be accomplished? With that in mind my fittings have been plugged for years until I get around to removing the hole mess for block-off plates!
I'm not asking this in an attempt to bust *****...just looking for something I missing?
My apologies to all... as this discussion should most likely take place on a different thread
I'm not asking this in an attempt to bust *****...just looking for something I missing?
My apologies to all... as this discussion should most likely take place on a different thread
07-15-2013, 04:51 PM
#12
Senior Member
SuperSport
Join Date: Aug 2010
Location: Toronto, Ontario, Canada
Posts: 506
http://api.viglink.com/api/click?for...13739321841206
flipped to keep the PAIR reed from opening at all.
Here is the link to the knowledge base.
https://www.superhawkforum.com/forum...val-how-20918/
Cheapest way to do it for sure.
flipped to keep the PAIR reed from opening at all.
Here is the link to the knowledge base.
https://www.superhawkforum.com/forum...val-how-20918/
Cheapest way to do it for sure.
09-16-2014, 11:49 PM
#13
Member
Squid
Squid
Join Date: Mar 2009
Location: Sherman Island, Ca.
Posts: 53
Yeah.......So??? I still do not get it! The reeds don't even need to be there!!!!!!
Once the vacuum is gone to the valve covers (block-off plates or what ever.... which is all too easy to do)...what's left????
Positive Waves!!! <<<<<<<correct.................................. .?
What happens to the + pos. waves...coming up the air passage from the exhaust ports... after the o-ring in the valve cover fails?
My guess is, some immeasurable amounts of pos, and neg. waves go through the valve covers and into the "stock air box"...
Making an already (tough-tune) set-up, just a bit more ponderous???
To me, the question is....I want to find the best way to plug the (Pair passages) @ the exhaust ports???
Seems like some may be under thinking this backside thought?
Once the vacuum is gone to the valve covers (block-off plates or what ever.... which is all too easy to do)...what's left????
Positive Waves!!! <<<<<<<correct.................................. .?
What happens to the + pos. waves...coming up the air passage from the exhaust ports... after the o-ring in the valve cover fails?
My guess is, some immeasurable amounts of pos, and neg. waves go through the valve covers and into the "stock air box"...
Making an already (tough-tune) set-up, just a bit more ponderous???
To me, the question is....I want to find the best way to plug the (Pair passages) @ the exhaust ports???
Seems like some may be under thinking this backside thought?
09-17-2014, 02:04 AM
#14
Senior Member
SuperBike
Join Date: Mar 2012
Location: New South Wales Australia
Posts: 1,544
Flip the reeds.
Mine has been like that for 2 years and no probs.
Don't understand how it does work but it does.
The only thing you need is caps for where the hoses went to seal them off.
Try it you'll see it works.
All up cost 1buck for caps and a bit of time.
I always said I would buy some aftermarket plates but have never bothered.
Mine has been like that for 2 years and no probs.
Don't understand how it does work but it does.
The only thing you need is caps for where the hoses went to seal them off.
Try it you'll see it works.
All up cost 1buck for caps and a bit of time.
I always said I would buy some aftermarket plates but have never bothered.
