Spark plug reading

Old 09-11-2013, 07:58 PM
  #1
Member
Squid
Thread Starter

Fistfullofthrotl718's Avatar

Join Date: Jul 2013
Location: Summerville, SC
Posts: 57
Fistfullofthrotl718 is on a distinguished road
Spark plug reading

to lean? Same plug, front cylinder, differant angles.

Name:  Picture219_zpsa3a223ce.jpg
Views: 37
Size:  59.8 KB

Name:  Picture221_zpse6bdaa55.jpg
Views: 26
Size:  52.2 KB
Fistfullofthrotl718 is offline
Old 09-11-2013, 11:04 PM
  #2
geezer
SuperSport

Join Date: Jan 2008
Location: Honolulu
Posts: 556
oahu hawk is on a distinguished road
Looks okay to me...

NGK Spark Plugs USA
oahu hawk is offline
Old 09-12-2013, 05:41 AM
  #3
Senior Member
SuperSport

sailorjerry's Avatar

Join Date: Oct 2012
Location: Orlando, FL
Posts: 501
sailorjerry is on a distinguished road
Originally Posted by Fistfullofthrotl718 View Post
to lean? Same plug, front cylinder, differant angles.




Cant get much better than that.
sailorjerry is offline
Old 09-12-2013, 05:48 AM
  #4
Moderator
MotoGP

E.Marquez's Avatar

Join Date: Apr 2006
Location: Kempner, TX
Posts: 4,255
E.Marquez is on a distinguished road
Spark Plug reading is very pre 1980.

The practice involving brand new never run plugs, a full throttle run with ignition & throttle chop at speed... then pulling the plugs to observe them worked very well before all the different gas additives and mixes or season gas came into play.

If you're hell bent on doing a plug "reading" ... get yourself some clean, fresh race gas.. two new plugs and a dyno or open road and a trailer to take the bike home.

That said...... "reading" plugs still has some limited usefulness.

The plug above shows no severe internal engine damage (no physical damage on the plug no sign of metal deposits), no serious oil getting past valve seals or rings, no signs of severe pre ignition....
So there is that

Last edited by E.Marquez; 09-12-2013 at 05:53 AM.
E.Marquez is offline
Old 09-12-2013, 07:27 AM
  #5
Senior Member
SuperBike

Join Date: Oct 2007
Location: Menifee, CA
Posts: 1,082
HRCA#1 is on a distinguished road
Reverting to my pre-80 plug reading days I would say your a tad rich, but Marquez is right fresh plugs and good gas and a clean throttle chop and you'll have better results.
HRCA#1 is offline
Old 09-12-2013, 07:38 AM
  #6
Senior Member
Superstock

insulinboy's Avatar

Join Date: Jul 2013
Location: Rome, GA
Posts: 458
insulinboy is on a distinguished road
Plug reading is more of a two stroke thing than four stroke. It used to be much more important than it is now (I used to do it all the time on my RD's) But I'd have to agree, that plug looks like its been burning puuurrr fectly
insulinboy is offline
