cam chain tensioner ?

I just bought a 98 superhawk and was using this forum to familiarize myself with the bike. I found several threads stating that the cct goes bad and to replace it with a manual one. My question is do they go bad instantly or are there signs like a noticable performance issue? I tried to use the search function to help but didn't find this answer. Only change it out or your bike will die lol. Thanks.
tomzxt is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-07-2011, 07:00 AM   #2
Out of my mind, back in 5
MotoGP

Tweety's Avatar

Join Date: Nov 2006
Location: Skurup, Sweden
Posts: 6,031
Tweety is on a distinguished road
Well... I honestly don't know how you managed to miss it, since it's been mentioned in just about any CCT thread to date, and is the main point of nearly all of those threads... But here we go again...

So, ask yourself this... If the conclusion you have made is, "change them or the bike dies!", doesn't that give you a clue?

The reason that they are discussed heavily on these forum's isn't that they fail... Almost all bikes have that to some extent... The reason is that on the VTR, when they fail, the result isn't just noise, and a mild repair bill...

On the VTR the failure is nearly always instant and catastophic... On very, very rare occasions have there been reports of someone getting enough warning to gently, coast to a stop without grabbing the clutch and grenading the top end of the engine...

Because that's what happens... Noise, from the failed CCT, followed by the CCT letting go completely when you pull the clutch and remove the tension from the cam chain... And that's really, really bad...
__________________
With me you get a package deal... The sarcasm comes free with the advice... If you wan't one or the other, use search...
<--- The result of OCMD... I gave up listing the mods in the sig...
Tweety is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-07-2011, 09:28 AM   #3
Light Cycle Expert
Back Marker

tomzxt's Avatar

Join Date: Mar 2011
Location: Tampa, Florida
Posts: 194
tomzxt is on a distinguished road
Thanks for the answer tweety.
tomzxt is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-07-2011, 09:31 AM   #4
Senior Member
SuperSport

ranchomice's Avatar

Join Date: Nov 2009
Location: Rancho Cordova, California
Posts: 671
ranchomice is on a distinguished road
Send a message via Yahoo to ranchomice
There are also those who have 80k on the stock ones. I'd rather have the peace of mind. I will be doing mine (again) at some point before 15k.
__________________
1998, Erion cans, fender hack, #48 pilots, Needle shim (0.40?), tps, pair/CA emissions removed (thanks Mike!), sargent seat, JDM revalve/respring, Superbrace, Electrosport R/R, smoked ZG DB.
ranchomice is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-07-2011, 12:39 PM   #5
Light Cycle Expert
Back Marker

tomzxt's Avatar

Join Date: Mar 2011
Location: Tampa, Florida
Posts: 194
tomzxt is on a distinguished road
I just bought a mint condition superhawk with 1700 miles so I wanted to be sure not to screw up a close to virgin engine.
tomzxt is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-08-2011, 11:05 AM   #6
Junior Member
Squid

Join Date: Jul 2010
Location: Papakura , Auckland , New Zealand
Posts: 9
jsteel is on a distinguished road
i have had two fail and both times i have had a noise first and through dum luck have made it home and changed them in time
jsteel is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-08-2011, 12:47 PM   #7
Light Cycle Expert
Back Marker

tomzxt's Avatar

Join Date: Mar 2011
Location: Tampa, Florida
Posts: 194
tomzxt is on a distinguished road
I'm changing mine next month. I hope this doesn't bite me in the butt. I just don't have the money for it right now after paying the Honda dealership $1300 already in maintenance and I just bought it!
tomzxt is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-08-2011, 03:03 PM   #8
Just hangin' out
Back Marker

klx678's Avatar

Join Date: Apr 2011
Location: Delaware, Ohio USA
Posts: 132
klx678 is on a distinguished road
For what it's worth, I just started making the Superhawk/Firestorm tensioners after someone here contacted me. Up to this point, I"ve done mostly Kawasaki tensioners since I had to make them for my own bikes. No one listed them for my bikes. When I made one I made five and started selling them. That was 2 years and over 200 tensioners ago.

The VTR tensioner kit has both tensioners with gaskets for $65 plus shipping. If you are interested feel free to PM or email me from this forum. I can fill you in on them
__________________
KLX650C, Zephyr 550, SR500 street/tracker in process, M27 Bultaco Sherpa T... sorry, no Superhawk, but am a fan of them since selling Hondas up until about 2006.

maker of Krieger Cam Chain Tensioners, here to answer any questions should there be any... and throw in my "two cents" on some subjects of interest.
klx678 is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-09-2011, 05:55 AM   #9
Senior Moments
SuperSport

CrankenFine's Avatar

Join Date: Aug 2010
Location: Pittsburgh
Posts: 905
CrankenFine is on a distinguished road
Quote:
Originally Posted by klx678 View Post
For what it's worth, I just started making the Superhawk/Firestorm tensioners after someone here contacted me. Up to this point, I"ve done mostly Kawasaki tensioners since I had to make them for my own bikes. No one listed them for my bikes. When I made one I made five and started selling them. That was 2 years and over 200 tensioners ago.

The VTR tensioner kit has both tensioners with gaskets for $65 plus shipping. If you are interested feel free to PM or email me from this forum. I can fill you in on them
How many of the SuperHawk tensioners have you made and sold so far, if I may ask?
__________________
'02 Honda Super Hawk- PAIRectomy, Superdutyd blocker plates, Sonic .90 Springs, Kreiger MCCTs, JDM F4 shock, Sargent Seat, ZX6R R/R w Eastern Beaver kit, Archaicguy Mirror Extenders, TPS@507 ohms, Pirelli Diablo tires, Jardine high mount exhaust, T-Rex Sliders,Carb setup per 8541Hawk, Dr Honda velocity stacks, JackFlash fuel screws.
CrankenFine is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-09-2011, 06:54 AM   #10
Light Cycle Expert
Back Marker

tomzxt's Avatar

Join Date: Mar 2011
Location: Tampa, Florida
Posts: 194
tomzxt is on a distinguished road
klx678 wrote a lot more about it here: CHEAPER MANUAL CCTS!!
Sounds like a good product to me. Guy knows what he is talking about.
tomzxt is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-09-2011, 11:30 AM   #11
Just hangin' out
Back Marker

klx678's Avatar

Join Date: Apr 2011
Location: Delaware, Ohio USA
Posts: 132
klx678 is on a distinguished road
Quote:
Originally Posted by CrankenFine View Post
How many of the SuperHawk tensioners have you made and sold so far, if I may ask?
You won't find me BSing on this. I've just started making them for the VTR and have sold three sets, two waiting to get the gaskets, but none installed. I am sure we will all hear the results with the first installations. Of course that is also how I started with the tensioners for the various Kawasakis too. The only ones I had immediate knowledge of were the ones in my own bikes. Of course I can give you a lot of references if you wish, but I believe they are also printed up in the other thread.

The one on the KLX250 was remote engineered, working with a rider in Austin Texas and me in Delaware Ohio. Several pictures, some measurements, some phone calls, and some reverse engineering measurements done from scaling the pictures resulted in a tensioner prototype that worked exactly as it should. The compound angle offset of the thru bolt made it a bit of a concern, but we did good. The VTR with the 3mm offset was relatively easy in comparison. I'm pretty confident in the results that will happen based on the Kawasaki experience. Now I just need to find out about the thru bolt length by long distance experience. I just learned that on a different Kaw unit, using a 90mm bolt where a 110mm was needed. I shipped out the new longer bolt after a quick phone call from the rider, no problem.

The thing is it isn't that the part is rocket science, it is the cost and effort of making them yourself. If I had to hand cut, thread, and finish each one I did I wouldn't be selling them. The first dozen were hand cut and finished with three or four scrapped out with angled threads. My fingers got quite hot with the heat generated by cutting the bodies with a band saw - aluminum is very efficient at transferring heat! That is purely a pain in the butt. By working out a good method for manufacture I am able to make them at a low enough price for a rider to skip the headache of making them and help the rider who either doesn't have the tools, time, place, or skill to do them.

I care enough about doing right by the guys that I had two packages misplaced and I send out new ones without any reservation. I got one back because the house address was 26 instead of 25 and it took a month and a half to return from the UK. The rider in Canada got the other after a lengthy delay in customs (no notice of that though), then got the second one. He actually decided to pay me and sell the other one rather than bother to send it back (I was going to split the return shipping with him), I guess he liked the result of the one he installed. Another rider didn't like the fact that a manual tensioner will have light chain ticking when cold, quieting down after thermal expansion, and wanted to return the part. I refunded him and paid the return shipping too.

So I'm trying to do right and treat riders like I'd want to be treated. I will only post a comment if it is in a thread about the tensioners, not just blatantly spamming everything. I will also say "if it ain't broke, don't fix it" which I often say with the Kawasakis because they don't have catastrophic failure, they do it over time. Sounds like the VTR is in a different situation though. They can break big time.

I hope I've aleviated some concerns here.

By the way, after seeing your signature, I have a long diamond shaped prototype for the air cooled Suzuki GS1100, which I think fits a bunch of other ones like possibly the GS750, sitting on the shelf waiting to find out how long a bolt to put in it. The guy from Missippi who called me about it hasn't gotten back with me yet, know anyone who wants to play? I don't make 'em for the RE5 Wankels though... not much demand for them...

Yeah, I know... I've been around for a while and know what they are. A friend has a few Hercules Wankels, one with a sidecar.
__________________
KLX650C, Zephyr 550, SR500 street/tracker in process, M27 Bultaco Sherpa T... sorry, no Superhawk, but am a fan of them since selling Hondas up until about 2006.

maker of Krieger Cam Chain Tensioners, here to answer any questions should there be any... and throw in my "two cents" on some subjects of interest.

Last edited by klx678; 04-09-2011 at 11:43 AM.
klx678 is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-09-2011, 12:47 PM   #12
Moderator
SuperBike

E.Marquez's Avatar

Join Date: Apr 2006
Location: Kempner, TX
Posts: 2,445
E.Marquez is an unknown quantity at this point
Quote:
Originally Posted by tomzxt View Post
I'm changing mine next month. I hope this doesn't bite me in the butt. I just don't have the money for it right now after paying the Honda dealership $1300 already in maintenance and I just bought it!
$1300.00???? What did they do, remove the third eye light and roll a new VTR underneath ?
If I may ask,,,, what service did you have done for that kind of $$$$$ If it's posted elsewhere, just point me in the right direction.
__________________
DMr shifter, Factory-Pro shift kit, Hawk basic carb setup, Bafflectomy, APEX bars, Ride-It Billet levers, V4 SpeedOHealer, DMr F4I rear shock upgrade w/RaceTech GV, Showa 41mm forks Reworked by DMr, F4I calipers loaded with Vesrah RJL Pads, RC51 MC, SS lines, Powerbronze Undertail and lower, Coil on CAP MOD, FH012 R/R with updated sealed plugs from Eastern Beaver, Lightened flywheel, Sergeant Seat, Vista Cruise Throttle lock
E.Marquez is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-09-2011, 01:00 PM   #13
Senior Member
SuperBike

Wicky's Avatar

Join Date: Sep 2008
Location: Essex, UK
Posts: 1,154
Wicky is on a distinguished road
I'm one of the first UK customers who've ordered a set from klx678, not for for me but for a friend who's returned to biking after having rugrats and got herself a storm (guess what she had before sprogging..) anyhow, she got herself a '98 with OEM CCTs and having myself gone through imploding an CCT on a '9 with 35k (no warning whatsoever of impending doom) I wouldn't want anyone to go through the resulting new head and mechanics bill to have it all put back together, and the time off-the-road - it's a no-brainer to fit manuals ASAP.

klx678 has been double and triple checking the dimensions, and I've pointed him towards the CCT fitting workshop threads, plus when I get his delivered will be doing photos and a write up during fitting as way of thanks for offering such a enthusiastic service.

If you haven't seen it already his website shows his dedication and testaments to his CCts: kriegercamchaintensioners.com
__________________
It may be that your whole purpose in life is simply to serve as a warning to others.

'97 FireStorm -Dynojetted - K&N Filter - Moriwaki Ti Zero Cans - Ohlins Rear Shock - Hagon Forks - FlipUp Screen - Heated Grips - Baglux Tank Cover.
Wicky is online now
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-09-2011, 01:25 PM   #14
Light Cycle Expert
Back Marker

tomzxt's Avatar

Join Date: Mar 2011
Location: Tampa, Florida
Posts: 194
tomzxt is on a distinguished road
Arrow

Quote:
Originally Posted by E.Marquez View Post
$1300.00???? What did they do, remove the third eye light and roll a new VTR underneath ?
If I may ask,,,, what service did you have done for that kind of $$$$$ If it's posted elsewhere, just point me in the right direction.
In a sense the sort of did put a new one underneath. The guy I purchased the hawk from found it from somebody who was in the military that bought it new and let it sit while being shipped out. It was in an air controlled storage unit which kept the body mint.

The bad news for me however, is that while sitting until now the tank had rusted and the carbs were in poor shape. Somehow the seller got the bike running and I heard and saw it. With only 1700 miles I bought it thinking I was getting a deal. Mint body, 1700 miles, sounded like a strong motor. Needless to say the rust was an issue about 20 minutes after I purchased it.

I replaced the fuel tank for $450 and both fuel filters $20x2 then drained the bowls to see if that would do the trick. When that didn't work I took the carbs off and apart to clean them out. When that didn't work I had had enough and brought it to the closest Honda dealer where their rate is $85 and hour.

They proceeded to tell me I needed to have my carbs rebuilt, a new battery, new air filter, PO blocked off four vacuum lines and a few more were missing so I needed to have that looked into, I wanted two new tires to replace the dry rotted stock ones, replace the spark plugs, and change the oil.

Just what the shop did came out to be 1300ish after tax. They wanted more originally. I told them they'd better try again on the price and got it down to what it is now. A lot of the services they sold me I could have done myself but they said in order to do the job THEY had to do it all or nothing.

Good news is with the exception of the CCTs I will not have to worry about anything for a long time I'm doing the CCTs next month after I build back up some money. Right now I am in the bike for $4900 and not too happy about it. Once I get it back I'm sure I'll be in a lot better mood. It just sucks right now not having something that you have paid that much for.
tomzxt is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-10-2011, 07:33 AM   #15
Just hangin' out
Back Marker

klx678's Avatar

Join Date: Apr 2011
Location: Delaware, Ohio USA
Posts: 132
klx678 is on a distinguished road
Talk about rusted tanks, I saw one to end all. An 88 Hawk GT that had blisters all around the top area. Each tiny blister was a spot of rust - from the inside out! The blistering ended at the fuel level of what had remained in the tank for about 20 years or so. Bike had 2300 miles, stored in a shed, what a shame. Worse yet the guy has a Norton in at least as bad of shape. The GT is in the process of being redone now. The Norton, heaven only knows...

But rust from the inside on the top of the tank... wow!
klx678 is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-10-2011, 08:19 AM   #16
Member
Squid

Join Date: Mar 2011
Location: Fort Dix, NJ
Posts: 83
b1m3x8 is on a distinguished road
Since we are on the topic, does anyone know what a Honda dealer would typically charge to get your CCT's replaced?
b1m3x8 is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-10-2011, 02:49 PM   #17
Senior Moments
SuperSport

CrankenFine's Avatar

Join Date: Aug 2010
Location: Pittsburgh
Posts: 905
CrankenFine is on a distinguished road
Quote:
Originally Posted by klx678 View Post
You won't find me BSing on this. I've just started making them for the VTR and have sold three sets, two waiting to get the gaskets, but none installed. I am sure we will all hear the results with the first installations. .
Can you post a note when you've satisfied your R&D phase and they go into production? I am interested in set.

Quote:
Originally Posted by klx678 View Post
By the way, after seeing your signature, I have a long diamond shaped prototype for the air cooled Suzuki GS1100, which I think fits a bunch of other ones like possibly the GS750, sitting on the shelf waiting to find out how long a bolt to put in it. The guy from Missippi who called me about it hasn't gotten back with me yet, know anyone who wants to play? I don't make 'em for the RE5 Wankels.
I should clarify that stuff in my sig. All the bikes other than the SuperHawk are former rides, retired or sold. Honestly if I saw another RE5 I'd run the other way. It pulled like a John Deere up hills but a total PITA to keep running, a truly bizarre piece of motorcycle history and belongs in museum. That's where mine is.
__________________
'02 Honda Super Hawk- PAIRectomy, Superdutyd blocker plates, Sonic .90 Springs, Kreiger MCCTs, JDM F4 shock, Sargent Seat, ZX6R R/R w Eastern Beaver kit, Archaicguy Mirror Extenders, TPS@507 ohms, Pirelli Diablo tires, Jardine high mount exhaust, T-Rex Sliders,Carb setup per 8541Hawk, Dr Honda velocity stacks, JackFlash fuel screws.
CrankenFine is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-10-2011, 05:57 PM   #18
Light Cycle Expert
Back Marker

tomzxt's Avatar

Join Date: Mar 2011
Location: Tampa, Florida
Posts: 194
tomzxt is on a distinguished road
Arrow

Quote:
Originally Posted by b1m3x8 View Post
Since we are on the topic, does anyone know what a Honda dealer would typically charge to get your CCT's replaced?
I got two quotes last week. The first was for $425 + parts from the dealer I was getting the work done at. They said that was a "deal" since the book called for 7 hours and they were only charging me for a max of 5. They'd start the clock and if it took less then I'd only get charged for that.
The second quote is much more reasonable @ $304 + parts.I'm taking it to the second one because they knew right what I was talking about before I even finished asking.
If the mechanic has to use the book for everything you don't want him touching your stuff. Of course it could have been the service writer trying to jack up the price for a bigger cut. Luckily for me this isn't my first bike and I researched prices and time frames before I asked for a quote.
tomzxt is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-10-2011, 06:21 PM   #19
Senior Member
SuperBike

RWhisen's Avatar

Join Date: Sep 2008
Location: Ft. Worth, TX
Posts: 1,605
RWhisen is on a distinguished road
Quote:
Originally Posted by b1m3x8 View Post
Since we are on the topic, does anyone know what a Honda dealer would typically charge to get your CCT's replaced?
This is not something you want the dealer to do for you. We have a forum member here who found this out the hard way. It ended up being a 3-4 month wait on his bike while the dealership rebuilt his engine after screwing up the install. It is not that tough to do and there are pictures in the KB section to help you along.
RWhisen is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-11-2011, 02:17 AM   #20
Out of my mind, back in 5
MotoGP

Tweety's Avatar

Join Date: Nov 2006
Location: Skurup, Sweden
Posts: 6,031
Tweety is on a distinguished road
Quote:
Originally Posted by tomzxt View Post
I got two quotes last week. The first was for $425 + parts from the dealer I was getting the work done at. They said that was a "deal" since the book called for 7 hours and they were only charging me for a max of 5. They'd start the clock and if it took less then I'd only get charged for that.
The second quote is much more reasonable @ $304 + parts.I'm taking it to the second one because they knew right what I was talking about before I even finished asking.
If the mechanic has to use the book for everything you don't want him touching your stuff. Of course it could have been the service writer trying to jack up the price for a bigger cut. Luckily for me this isn't my first bike and I researched prices and time frames before I asked for a quote.

7 Hours?!? Only if they hand make the CCT's in the shop does it take 7 hours... Or even 5 hours...

I think I had it done in under 2 hours and I was fumbling around a bit, plus supervising another guy (novice working on motocycles) doing the same for the first time on another VTR...
__________________
With me you get a package deal... The sarcasm comes free with the advice... If you wan't one or the other, use search...
<--- The result of OCMD... I gave up listing the mods in the sig...
Tweety is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-11-2011, 05:22 PM   #21
Just hangin' out
Back Marker

klx678's Avatar

Join Date: Apr 2011
Location: Delaware, Ohio USA
Posts: 132
klx678 is on a distinguished road
Quote:
Originally Posted by CrankenFine View Post
Can you post a note when you've satisfied your R&D phase and they go into production? I am interested in set.



I should clarify that stuff in my sig. All the bikes other than the SuperHawk are former rides, retired or sold. Honestly if I saw another RE5 I'd run the other way. It pulled like a John Deere up hills but a total PITA to keep running, a truly bizarre piece of motorcycle history and belongs in museum. That's where mine is.
At this point the only real R&D is how long the thru bolt should be. Right now they will come with 110mm until I know if I can go shorter.

I understood the service on the RE5, when it came to engine warranty, was to pull it out and replace it with a new one. They didn't have too good a rep for workability. Did you get a tax write off on the museum thing... or did you have to pay them to take it. Sorry. It just popped in my mind.
__________________
KLX650C, Zephyr 550, SR500 street/tracker in process, M27 Bultaco Sherpa T... sorry, no Superhawk, but am a fan of them since selling Hondas up until about 2006.

maker of Krieger Cam Chain Tensioners, here to answer any questions should there be any... and throw in my "two cents" on some subjects of interest.
klx678 is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-11-2011, 07:39 PM   #22
Senior Moments
SuperSport

CrankenFine's Avatar

Join Date: Aug 2010
Location: Pittsburgh
Posts: 905
CrankenFine is on a distinguished road
Quote:
Originally Posted by klx678 View Post
I understood the service on the RE5, when it came to engine warranty, was to pull it out and replace it with a new one. They didn't have too good a rep for workability. Did you get a tax write off on the museum thing... or did you have to pay them to take it. Sorry. It just popped in my mind.
That's true, Suzuki dealers "fixed" the engine by swapping it. I got neither a tax break nor a bill for the privilege of donating it. Let's just say I got to stop shoveling money into that particular hole and walk away...

10-4 on the R&D. I guess I thought you were indicating you would move on from machining them by hand to some automated CNC type process, and that you were awaiting some customer feedback to confirm it's ready to produce.
__________________
'02 Honda Super Hawk- PAIRectomy, Superdutyd blocker plates, Sonic .90 Springs, Kreiger MCCTs, JDM F4 shock, Sargent Seat, ZX6R R/R w Eastern Beaver kit, Archaicguy Mirror Extenders, TPS@507 ohms, Pirelli Diablo tires, Jardine high mount exhaust, T-Rex Sliders,Carb setup per 8541Hawk, Dr Honda velocity stacks, JackFlash fuel screws.
CrankenFine is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-12-2011, 03:29 AM   #23
Senior Member
Back Marker

insider's Avatar

Join Date: Sep 2009
Posts: 161
insider is on a distinguished road
So I don't start a new thread on CCTs.

I currently have a '97 Firestorm with 45.900km onboard (stock ccts).

I really worried about this issue so I'm thinking options on how to avoid failure.

If I wanna go down the 'stock road' (as in getting new tensioners), what else should I change?

The two camchains, the two tensioners,and what else? Or can I just change the tensioners leaving the chains?
Changing the chains involes changing the cam sprockets?

If I wanna go the APE CCTs road i'm not technical at all, and I don't know if I can have somebody change them for me, do they have to be familiar with vtr cam chains? or any mechanic who works on bikes can do the job of adjusting them?
insider is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-12-2011, 03:50 AM   #24
Out of my mind, back in 5
MotoGP

Tweety's Avatar

Join Date: Nov 2006
Location: Skurup, Sweden
Posts: 6,031
Tweety is on a distinguished road
Insider, you can do it yourself or have a good workshop just swap out the stock CCT's for new stock one's or APE's... No need to swap the chains unless they are out of service spec...

Keep in mind that if you select stock CCT's you will then need this to be done again at some point...

There really is no difference in terms of complexity when you choose between the two... The work to swap them out is the same except for adjustment, and for that there is excelent instructions avialable, so any competent mechanic can do that...

But, and there is a big, important but here... Do not make the mistake of going to the shop and simple asking them to swap the CCT's and take it on faith that they know what they are doing...

The big difference between the VTR, and 99.99% of all other bikes are that on other bikes, if the CCT fails, or is installed incorrectly, it makes noise and in long term can harm he engine... On the VTR it goes, crunch-crunch and costs money the first second the CCT isn't operating properly... Doesn't matter if it's a stock CCT that was installed improperly or a manual that was either improperly installed or adjusted...

Bottom line... It costs money the second the CCT's fail to work properly... So if you get a shop to do the work for you, make very, very sure to discuss this important fact with them, and it might be a good idea to print out the excellent material on other threads on this site to show them...

Apart from the need to impress this simple fact on them, there is no need fort them to be familiar with the VTR specifically...
__________________
With me you get a package deal... The sarcasm comes free with the advice... If you wan't one or the other, use search...
<--- The result of OCMD... I gave up listing the mods in the sig...
Tweety is offline
Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiTweet this Post!
Reply With Quote
Old 04-12-2011, 03:50 AM



Reply

Tags
175, 98, adjust, adjustment, air, cam, chain, controled, gs1100, krieger, ss, superhawk, suzuki, tensioner, tightener

Thread Tools Search this Thread
Search this Thread:

Advanced Search
Display Modes

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are On
Pingbacks are On
Refbacks are On



All times are GMT -7. The time now is 01:50 PM.



Honda and the Honda marquee are registered trademarks of the American Honda Motor Company, Inc. Neither American Honda Motor Company nor its subsidiaries or affiliates shall bear any responsibility for SuperHawkforum.com content, comments, or advertising. SuperHawkforum.com is not affiliated with American Honda Motor Company in any way. American Honda Motor Company does not sponsor, support, or endorse SuperHawkforum.com in any way. Copyright/trademark/sales mark infringements are not intended or implied.

Advertising

SEO by vBSEO ©2010, Crawlability, Inc.
